770278-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG W/DETENT 1POS .062
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
≥10 USD $0.19536
≥100 USD $0.177232
≥500 USD $0.12789
≥1000 USD $0.113318
≥3000 USD $0.100373
Inventory: 2929
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 months ago)
Physical
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Published 1997
Series Commercial .062 Pin and Socket
JESD-609 Code e4/e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Voltage - Rated 250V
HTS Code 8536.69.40.30
Fastening Type Detent Lock
Contact Finish - Mating GOLD/TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male or Female
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.68mm
Orientation Straight
Depth 7.75mm
Current Rating 7A
Approval Agency CSA
Number of Contacts 1
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
UL Flammability Code 94V-2
Empty Shell NO
Operating Supply Voltage 250V
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 250V
Wire/Cable Type Discrete
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 30 AWG
Max Voltage Rating (DC) 250.25kV
Sealable No
Circuit Application Power
Contact Termination Crimp
Insulation Diameter 2.79 mm
Contact Retention Without
Dimensions
Length 19.304mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
