770036-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Universal MATE-N-LOK II RoHS Compliant 1997 Straight Plug, Rear Section Connector Housing UL94V-0 120C 19A 600V
PDF
/
Buying Options
Total Price: USD $3.52
Unit Price: USD $3.522497
≥1 USD $3.522497
≥10 USD $3.323102
≥100 USD $3.135009
≥500 USD $2.957555
≥1000 USD $2.79014
Inventory: 4423
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Published 1997
Series Universal MATE-N-LOK II
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug, Rear Section
Max Operating Temperature 120°C
Min Operating Temperature -55°C
Color White
Number of Rows 1
Voltage - Rated 600V
Fastening Type Latch Lock
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male or Female
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 6.35mm
Orientation Straight
Current Rating 19A
Approval Agency CSA
Number of Contacts 4
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
Housing Color Natural, White
Empty Shell NO
Operating Supply Voltage 600V
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 600V
Max Current Rating 19A
Sealable No
Contact Termination Crimp
Contact Retention Without
VDE Tested Yes
Dimensions
Height 21.463mm
Length 26.67mm
Width 7.62mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
