770031-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings 02P PLUG-FRONT 94VO
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.36344
≥100 USD $0.362208
≥500 USD $0.349888
≥1000 USD $0.293392
≥3000 USD $0.275018
Inventory: 3030
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 7.62mm
Length 13.97mm
Height 22.987mm
Technical
VDE Tested Yes
Contact Retention Without
Contact Termination Crimp
Sealable No
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Operating Supply Voltage 600V
Empty Shell NO
Housing Color Natural, White
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 2
Approval Agency CSA
Current Rating 19A
Depth 22.99mm
Orientation Straight
Pitch 6.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male or Female
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
HTS Code 8536.69.40.30
Voltage - Rated 600V
Number of Rows 1
Color White
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Connector Type Plug, Front Section
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK II
Published 1997
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 13 Weeks
Alternative Model
