7-179228-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CT CRIMP-2 REC HSG 10P BLACK
PDF
/
Inventory: 2354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Shape Rectangular
Technical
Packaging Bulk
Published 2009
Series CT
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 10
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Color Black
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 10
Orientation Straight
Current Rating 4A
Approval Agency CSA
UL Flammability Code 94V-0
Operating Supply Voltage 125V
Insulation Resistance 1GOhm
Note Contacts Not Included
ELV Compliant
Wire/Cable Gauge 22 AWG
Sealable No
Contact Current Rating 4A
Contact Termination Crimp
Mating Retention Without
Dimensions
Height 6.604mm
Length 21.99894mm
Width 4.5974mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
