6-1123722-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
3.96 EP PLUG HSG 4P(GREEN)
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.30284
≥1 USD $0.30284
≥10 USD $0.2857
≥100 USD $0.26953
≥500 USD $0.25427
Inventory: 6430
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 13.3096mm
Length 15.78mm
Height 10.4902mm
Technical
Contact Retention Without
Insulation Diameter 2.9972 mm
Contact Termination Crimp
Contact Current Rating 8A
Sealable No
ELV Compliant
Note Contacts Not Included
Insulation Resistance 1GOhm
Operating Supply Voltage 250V
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Current Rating 8A
Orientation Straight
Total Number of Contacts 4
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
Number of Rows 1
Color Green
Min Operating Temperature -25°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Economy Power
Published 2005
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE66
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 14 Weeks
