440146-9 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description CONN RCPT 9POS SGL 1.25MM NATRL
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.13728
≥100 USD $0.114576
≥500 USD $0.095278
≥1000 USD $0.079913
≥3000 USD $0.07025
Inventory: 11728
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Width 3.9624mm
Length 13mm
Height 3.1496mm

Technical

Mating Retention Without
Contact Termination Crimp
Contact Current Rating 1A
Sealable No
Wire/Cable Gauge 28 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 30 AWG
Max Voltage Rating (AC) 250V
ELV Compliant
Note Contacts Not Included
Insulation Resistance 100MOhm
Operating Supply Voltage 100V
Housing Color Natural, White
Contact Gender Female
Number of Contacts 9
Current Rating 1A
Depth 3.95mm
Orientation Straight
Pitch 0.049 1.25mm
Contact Type Female Socket
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 9
Connector Type Receptacle
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series HPI
Published 2005
Packaging Bulk

Physical

Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 13 Weeks
