440129-7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
HPI RoHS Compliant COMMERCIAL UL Receptacle Connector Housing 50Cycles UL94V-0 24AWG 85C
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.17424
≥100 USD $0.173888
≥500 USD $0.1716
≥1000 USD $0.158488
≥3000 USD $0.130275
Inventory: 43448
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 6.9mm
Length 15.8mm
Height 4.4958mm
Technical
Wire Size (Max) 24 AWG
Wire Size (Min) 30 AWG
Insulation Diameter 1.4986 mm
Mating Retention With
Contact Termination Crimp
Contact Current Rating 3A
Sealable No
Durability 50 Cycles
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style PLUG
Note Contacts Not Included
Insulation Resistance 1GOhm
Rated Current (Signal) 3A
Operating Supply Voltage 250V
UL Flammability Code 94V-0
Contact Gender Female
Reliability COMMERCIAL
Reference Standard UL
Current Rating 3A
Depth 6.9mm
Orientation Straight
Total Number of Contacts 7
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Color Natural
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 7
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series HPI
Published 2005
Packaging Bulk
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 13 Weeks
