4-87499-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING 22POS .100 SINGLE
PDF
/
Buying Options
Total Price: USD $3.83
Unit Price: USD $3.828
≥1 USD $3.828
≥10 USD $3.40912
≥100 USD $3.026848
≥500 USD $2.487584
Inventory: 573
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 15.24mm
Length 56.01mm
Height 3.56mm
Technical
Wire Size (Max) 20 AWG
Wire Size (Min) 32 AWG
Contact Termination Crimp
Contact Current Rating 3A
Max Voltage Rating (AC) 250V
ELV Compliant
Body/Shell Style PLUG
Note Contacts Not Included
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Rated Current (Signal) 3A
Operating Supply Voltage 250V
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Current Rating 3A
Depth 15.24mm
Orientation Straight
Total Number of Contacts 22
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male or Female
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 22
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPMODU Mod IV
Published 2008
Packaging Bulk
Physical
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging, Surface Mount
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 4 Weeks
