4-1563759-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
18POS,AMP MCP1.5K,REC HSG,ASSY
PDF
/
Buying Options
Total Price: USD $3.68
Unit Price: USD $3.6784
≥1 USD $3.6784
≥10 USD $3.27448
≥100 USD $2.907212
≥500 USD $2.389244
Inventory: 925
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 25.7mm
Length 67.2mm
Height 31.242mm
Technical
Polarized Yes
Hybrid Connector No
Mating Tab Width 1.6002mm
Contact Termination Crimp
Circuit Application Signal
ELV Compliant
Note Contacts Not Included
Row Spacing 0.236 (6.00mm)
Housing Color Black
Pitch 0.157 4.00mm
Contact Type Female Socket
Fastening Type Slide-On
HTS Code 8536.69.40.30
Number of Rows 2
Color Blue
Min Operating Temperature -40°C
Max Operating Temperature 140°C
Number of Positions 18
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed
Series Heavy Duty Sealed Connector Series (HDSCS), MCP 1.5K
Published 2012
Packaging Bulk
Physical
Body Material PBT
Mounting Type Free Hanging (In-Line)
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 10 Weeks
