368545-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Automotive Connectors 070 MLC CAP 2P HSG
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.114132
≥1 USD $0.114132
≥10 USD $0.107673
≥100 USD $0.101577
≥500 USD $0.095827
≥1000 USD $0.090405
Inventory: 6693
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 15.8mm
Length 11.6mm
Height 30.8991mm

Technical

Polarized Yes
Hybrid Connector No
Mating Tab Width 1.8mm
Contact Termination Crimp
Circuit Application Signal
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 16 AWG
ELV Compliant
Note Contacts Not Included
Housing Color Natural
Number of Contacts 2
Current Rating 14A
Depth 30.9mm
Orientation Straight
Pitch 0.138 3.50mm
Contact Type Tab
Fastening Type Latch Holder
Gender Male
Number of Rows 1
Color Natural
Min Operating Temperature -30°C
Max Operating Temperature 105°C
Number of Positions 2
Connector Type Receptacle
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multi-Lock
Published 2008
Packaging Bulk

Physical

Body Material PBT
Housing Material Polybutylene
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 18 Weeks
