RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Standard Timer RoHS Compliant 2004 Straight Receptacle Connector Housing UL94V-2 14.4mm
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.054313
≥1 USD $1.054313
≥10 USD $0.994632
≥100 USD $0.938336
≥500 USD $0.885225
≥1000 USD $0.835122
Inventory: 4766
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-2
RoHS Status RoHS Compliant

Dimensions

Length 25mm
Height 14.4mm

Technical

Mating Retention With
Contact Termination Crimp
Sealable No
Note Contacts Not Included
Empty Shell NO
UL Flammability Code 94V-2
Orientation Straight
Total Number of Contacts 5
Pitch 0.197 5.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
Additional Feature POLARIZED, LATCH
Number of Rows 1
Color Blue
Number of Positions 5
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Standard Timer
Published 2004
Packaging Bulk

Physical

Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 8 Weeks
