284972-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Housing RCP 52 POS Crimp ST Cable Mount
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5552
≥1 USD $3.5552
≥10 USD $3.17152
≥100 USD $3.154976
≥500 USD $3.122592
≥1000 USD $2.815296
≥3000 USD $2.799086
Inventory: 328
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 23.495mm
Length 34.8996mm
Height 54mm
Technical
Serviceable Yes
Hybrid Connector No
Mating Tab Width 635μm
Contact Termination Crimp
Circuit Application Signal
ELV Compliant
Note Contacts Not Included
Row Spacing 2.9972 mm
Depth 54mm
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Lever Lock
Gender Female
Number of Rows 4
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 52
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Micro Quadlok
Published 2011
Packaging Bulk
Physical
Body Material PBT
Housing Material Polybutylene
Mounting Type Free Hanging (In-Line)
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 14 Weeks
