207018-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT 12 POS METRIMATE
PDF
/
Buying Options
Total Price: USD $8.77
Unit Price: USD $8.7736
≥1 USD $8.7736
≥10 USD $7.64632
≥100 USD $6.80152
≥500 USD $5.674654
Inventory: 728
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Copper, Gold
Mount Free Hanging, Panel
Mounting Type Free Hanging (In-Line)
Material Thermoplastic
Housing Material Nylon
Technical
Packaging Bulk
Published 1998
Series Metrimate
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 12
Max Operating Temperature 130°C
Min Operating Temperature -55°C
Color Black or Red
Number of Rows 3
Fastening Type Latch Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts YES
Option GENERAL PURPOSE
Pitch 0.197 5.00mm
Total Number of Contacts 12
Orientation Straight
Depth 33.02mm
Current Rating 13A
Reliability COMMERCIAL
Approval Agency UL
UL Flammability Code 94V-0
Housing Color Red, Black
Empty Shell YES
Operating Supply Voltage 600V
Rated Current (Signal) 7.5A
Insulation Resistance 5GOhm
Row Spacing 0.197 (5.00mm)
Note Contacts Not Included
Max Voltage Rating (AC) 600V
Max Current Rating 14A
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2000VAC V
Wire/Cable Type Discrete
Durability 250 Cycles
Insertion Force-Max 4.8928 N
Withdrawl Force-Min .278 N
Contact Termination Crimp and Solder
VDE Tested Yes
Dimensions
Length 23.8mm
Panel Thickness 2.29mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
