2-640251-4 image
Favorite
2-640251-4 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Headers & Wire Housings 24P SL156 HSG W/O LCK RAMP
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.72864
≥100 USD $0.69696
≥500 USD $0.68728
≥1000 USD $0.6006
≥3000 USD $0.57809
Inventory: 855
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)

Physical

Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon

Technical

Packaging Bulk
Published 2008
Series SL-156
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle
Number of Positions 24
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Number of Rows 1
Contact Type Female Socket
Pitch 0.156 3.96mm
Orientation Straight
Depth 16.76mm
Current Rating 6.5A
Approval Agency CSA
Shrouding No
Number of Contacts 24
Contact Gender Female
Housing Color Natural, White
Operating Supply Voltage 250V
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 250V
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 24 AWG
Sealable No
Contact Current Rating 6.5A
Contact Termination Crimp
Mating Retention Without

Dimensions

Height 6.35mm
Length 95.1484mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
