2-640251-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings 22P SL156 HSG W/O LCK RAMP
PDF
/
Inventory: 3015
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 2008
Series SL-156
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle
Number of Positions 22
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Number of Rows 1
Contact Type Female Socket
Pitch 0.156 3.96mm
Orientation Straight
Depth 16.76mm
Current Rating 6.5A
Approval Agency CSA
Shrouding No
Number of Contacts 22
Housing Color Natural
Operating Supply Voltage 250V
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 250V
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 18 AWG
Sealable No
Contact Current Rating 6.5A
Contact Termination Crimp
Mating Retention Without
Dimensions
Height 6.35mm
Length 87.1982mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
