2-1586000-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 24POS FREE HANGING
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
≥10 USD $0.27368
≥100 USD $0.272096
≥500 USD $0.265232
≥1000 USD $0.227568
≥3000 USD $0.205832
Inventory: 887
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 2005
Series VAL-U-LOK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug
Max Operating Temperature 221°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 2
Voltage - Rated 600V
Fastening Type Locking Ramp
Contact Type Male Pin
Pitch 0.165 4.20mm
Orientation Straight
Depth 23.8mm
Current Rating 9A
Voltage - Rated AC 600V
Approval Agency CSA
Number of Contacts 24
Contact Gender Male
Operating Supply Voltage 600V
Insulation Resistance 1GOhm
Row Spacing 0.165 (4.20mm)
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Sealable No
Contact Termination Crimp
Insulation Diameter 3.0988 mm
Contact Retention Without
Dimensions
Height 9.6mm
Length 51.5874mm
Width 23.8mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
