2-1564546-1 image
Favorite
2-1564546-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description 2POS,TAB 5.8X0.8,TAB HSG,ASSY
PDF
/
Buying Options
Total Price: USD $2.93
Unit Price: USD $2.9304
≥1 USD $2.9304
≥10 USD $2.60832
≥100 USD $2.595296
≥500 USD $2.56872
≥1000 USD $2.315808
≥3000 USD $2.302502
Inventory: 104
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Mounting Type Panel Mount
Body Material PBT

Technical

Packaging Bulk
Published 2011
Series Heavy Duty Sealed Connector Series (HDSCS), MCP 6.3
Feature Mounting Flange, Sealed
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug
Number of Positions 2
Max Operating Temperature 140°C
Min Operating Temperature -40°C
Color Gray
Number of Rows 1
Fastening Type Slide-On
Contact Type Tab
Pitch 0.354 9.00mm
Housing Color Grey
Note Contacts Not Included
ELV Compliant
Circuit Application Signal
Contact Termination Crimp
Mating Tab Width 5.7912mm
Hybrid Connector No
Polarized Yes

Dimensions

Height 39.79926mm
Length 42.49928mm
Width 50.59934mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
