2-103653-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings 22 MTE SHRD PIN HSG SR LATCH
PDF
/
Inventory: 1564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Bronze
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Packaging Bulk
Published 2008
Series AMPMODU MTE
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Plug
Number of Positions 22
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Fastening Type Latch Holder
Contact Type Male Pin
Pitch 0.100 2.54mm
Orientation Straight
Depth 24.13mm
Current Rating 3A
Number of Contacts 22
Contact Gender Male
Housing Color Black
Operating Supply Voltage 250V
Row Spacing 2.54 mm
Note Contacts Not Included
ELV Compliant
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 22 AWG
Wire/Cable Gauge 30 AWG
Contact Current Rating 3A
Contact Termination Crimp
Dimensions
Height 6.604mm
Length 58.166mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
