178602-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors 070 MULTILOC CAP HSG PANEL LOC
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.88176
≥100 USD $0.758912
≥500 USD $0.598946
≥1000 USD $0.541508
≥3000 USD $0.507716
Inventory: 4447
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Cable, Panel
Mounting Type Panel Mount
Shell Material POLYBUTYLENE TEREPHTHALATE
Housing Material PBT
Technical
Packaging Bulk
Published 1997
Series Multi-Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 2
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color White
Number of Rows 1
Fastening Type Board Latch
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Tab
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.138 3.50mm
Total Number of Contacts 2
Orientation Straight
Depth 30.9mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
Empty Shell NO
Note Contacts Not Included
ELV Compliant
Termination Type SOLDER
Wire/Cable Type Discrete
Contact Termination Crimp
Keyed No
Dimensions
Length 20.6mm
Width 15.8mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
Lead Free Lead Free
