176287-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
AMP UNIVERSAL POWER CAP 9P
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
≥10 USD $0.52888
≥100 USD $0.52624
≥500 USD $0.508464
≥1000 USD $0.42636
≥3000 USD $0.399696
Inventory: 1639
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length 28.956mm
Height 17.6mm
Technical
Contact Retention Without
Contact Termination Crimp
Contact Current Rating 7A
Sealable No
Withdrawl Force-Min .6116 N
Insertion Force-Max 6.672 N
Durability 25 Cycles
Dielectric Withstanding Voltage 2200VAC V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.181 (4.60mm)
Insulation Resistance 1GOhm
Operating Supply Voltage 300V
Body Depth 1.142 inch
Empty Shell YES
Mating Information MULTIPLE MATING PARTS AVAILABLE
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 7A
Total Number of Contacts 9
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Tab
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Lock
Gender Female
Number of Rows 3
Color Red
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 9
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal Power
Published 1997
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 14 Weeks
