176278-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Housing PL 12 POS 3.96mm Crimp ST Cable Mount Loose Piece
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.50336
≥100 USD $0.357738
≥500 USD $0.313544
≥1000 USD $0.277772
≥3000 USD $0.260436
Inventory: 1180
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Mounting Option 2 LOCKING
Technical
Packaging Bulk
Published 1997
Series Universal Power
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Number of Positions 12
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color Black
Number of Rows 3
Gender Male
Fastening Type Latch Lock
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.156 3.96mm
Total Number of Contacts 12
Orientation Straight
Depth 19.3mm
Current Rating 7A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.62 inch
UL Flammability Code 94V-0
Empty Shell YES
Operating Supply Voltage 300V
Insulation Resistance 1GOhm
Row Spacing 0.181 (4.60mm)
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 600V
Dielectric Withstanding Voltage 2200VAC V
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 16 AWG
Durability 25 Cycles
Wire/Cable Gauge 26 AWG
Insertion Force-Max 6.672 N
Sealable No
Contact Current Rating 7A
Contact Termination Crimp
Contact Retention Without
Dimensions
Height 16.3mm
Length 19.304mm
Width 18.95mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
