1747366-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings DYNAMICD2800 TAB HSG 30P W/HTS CONN
PDF
/
Buying Options
Total Price: USD $3.81
Unit Price: USD $3.8104
≥1 USD $3.8104
≥10 USD $3.39504
≥100 USD $3.014176
≥500 USD $2.477182
Inventory: 2090
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Cable
Mounting Type Free Hanging (In-Line)
Housing Material Polyester
Technical
Packaging Bulk
Published 2005
Series Dynamic D-2800
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug
Number of Positions 30
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Black
Number of Rows 5
Gender Male
Fastening Type Latch Lock
Contact Type Tab
Pitch 0.118 3.00mm
Orientation Straight
Depth 40mm
Approval Agency UL
Number of Contacts 30
Housing Color Black
Operating Supply Voltage 250V
Row Spacing 0.148 (3.75mm)
Note Contacts Not Included
ELV Compliant
Wire/Cable Gauge 18 AWG
Sealable No
Circuit Application Signal
Contact Termination Crimp
Halogen Free Halogen Free
Preloaded No
VDE Tested No
Dimensions
Height 40mm
Length 19.4818mm
Width 30.3mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
