1586017-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Housing PL 4 POS 4.2mm Crimp ST Cable Mount
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.132
≥1 USD $0.132
≥10 USD $0.11176
≥100 USD $0.111584
≥500 USD $0.11
≥1000 USD $0.101728
≥3000 USD $0.0836
Inventory: 13251
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 23.8mm
Length 9.6mm
Height 9.6mm
Technical
Contact Retention Without
Insulation Diameter 3.0988 mm
Contact Termination Crimp
Sealable No
Durability 50 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.165 (4.20mm)
Rated Current (Signal) 9A
Operating Supply Voltage 600V
Housing Color White, Natural
Number of Contacts 4
Approval Agency CSA
Reliability COMMERCIAL
Depth 23.8mm
Orientation Straight
Pitch 0.165 4.20mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Lock
Gender Male
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series VAL-U-LOK
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging, Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 16 Weeks
