1565380-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Housing PL 28 POS 2.2mm Crimp ST Cable Mount Bag
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.4112
≥1 USD $2.4112
≥10 USD $2.1472
≥100 USD $2.135936
≥500 USD $2.113936
≥1000 USD $1.928344
Inventory: 527
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width 32.9946mm
Length 21mm
Height 15.7988mm
Technical
Polarized Yes
Hybrid Connector No
Mating Tab Width 635μm
Contact Termination Crimp
Circuit Application Signal
ELV Compliant
Note Contacts Not Included
Row Spacing 0.118 (3.00mm)
Depth 21mm
Orientation Straight
Pitch 0.087 2.20mm
Contact Type Female Socket
Fastening Type Locking Ramp
HTS Code 8536.69.40.30
Gender Male
Number of Rows 2
Color Natural
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 28
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series .025
Published 2005
Packaging Bulk
Physical
Body Material PBT
Housing Material Polybutylene
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 16 Weeks
