104257-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECPT 10POS .1" POL UNLOAD
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.1968
≥1 USD $1.1968
≥10 USD $1.11584
≥100 USD $0.846014
≥500 USD $0.757786
≥1000 USD $0.685124
≥3000 USD $0.642365
Inventory: 1265
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 25.3492mm
Height 5.08mm
Technical
Mating Retention With
Contact Termination Crimp
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 30 AWG
Max Current Rating 3A
Note Contacts Not Included
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Operating Supply Voltage 267V
Housing Color Black
Contact Gender Female
Number of Contacts 10
Lead Pitch 2.54mm
Approval Agency CSA, UL
Depth 15.24mm
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Latch Lock
Gender Receptacle
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 10
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU MTE
Published 2006
Packaging Bulk
Physical
Housing Material Thermoplastic
Number of Pins 10
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 13 Weeks
