103648-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Headers & Wire Housings RECPT HSG 2P
PDF
/
Buying Options
Total Price: USD $2.52
Unit Price: USD $2.52117
≥1 USD $2.52117
≥10 USD $2.18978
Inventory: 30
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 2.4892mm
Length 5.08mm
Height 2.4892mm

Technical

Contact Termination Crimp
Contact Current Rating 3A
Wire/Cable Gauge 30 AWG
ELV Compliant
Note Contacts Not Included
Row Spacing 2.54 mm
Operating Supply Voltage 250V
Housing Color Black
Contact Gender Female
Number of Contacts 2
Current Rating 3A
Depth 15.24mm
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Gender Receptacle
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 2
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU MTE
Published 2007
Packaging Bulk

Physical

Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging, Surface Mount
Contact Plating Gold
Contact Material Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 10 Weeks
