1-87175-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING 4POS .100 LOCKING
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.1968
≥1 USD $1.1968
≥10 USD $1.0912
≥100 USD $1.058464
≥500 USD $1.047904
≥1000 USD $0.972664
≥3000 USD $0.956525
Inventory: 1400
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 17.78mm
Length 10.56mm
Height 4.44mm
Technical
Mating Retention With
Contact Termination Crimp
Contact Current Rating 3A
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 30 AWG
Max Voltage Rating (AC) 250V
Body/Shell Style PLUG
Note Contacts Not Included
Row Spacing 2.54 mm
Insulation Resistance 5GOhm
Operating Supply Voltage 250V
Contact Gender Female
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 250V
Current Rating 3A
Depth 17.78mm
Orientation Straight
Total Number of Contacts 4
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPMODU
Published 1997
Packaging Bulk
Physical
Housing Material Polyester
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 10 Weeks
