1-770849-9 image
Favorite
1-770849-9 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description 19P SL156 HSG W/LCK RMP & TABS
PDF
/
Inventory: 7431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Length 75.311mm
Height 6.35mm

Technical

Mating Retention With
Contact Termination Crimp
Contact Current Rating 6.5A
Sealable No
Wire/Cable Gauge 24 AWG
ELV Compliant
Note Contacts Not Included
Operating Supply Voltage 250V
Housing Color Natural, White
Number of Contacts 19
Shrouding No
Approval Agency CSA
Current Rating 6.5A
Orientation Straight
Pitch 0.156 3.96mm
Contact Type Female Socket
Fastening Type Locking Ramp
Number of Rows 1
Color Natural
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 19
Connector Type Receptacle
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Polarizing Key
Series SL-156
Published 2008
Packaging Bulk

Physical

Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
