1-640525-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 24 POS MINI RECT
PDF
/
Buying Options
Total Price: USD $5.52
Unit Price: USD $5.5176
≥1 USD $5.5176
≥10 USD $4.83648
≥100 USD $4.329952
≥500 USD $3.595636
Inventory: 372
Minimum: 1
-
+
Technical Details
Technical
Max Current Rating 9A
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 26 AWG
Sealable No
Contact Termination Crimp
Insulation Diameter 2.921 mm
Max Voltage Rating (AC) 250V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.165 (4.20mm)
Operating Supply Voltage 250V
Empty Shell YES
Housing Color Red, Black
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 24
Approval Agency CSA
Current Rating 9A
Depth 27.56mm
Orientation Straight
Pitch 0.165 4.20mm
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Fastening Type Locking Ramp
Voltage - Rated 250V
Gender Female
Number of Rows 4
Color Black or Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series MR (Miniature Rectangular)
Published 1997
Packaging Bulk
Dimensions
Height 12.95mm
Length 21.336mm
Width 33.91mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
Physical
Housing Material Nylon
Mounting Type Panel Mount, Snap-In
Mount Free Hanging, Panel, Snap in
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 9 Weeks
