1-480709-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Power to the Board CAP HOUSE 12 POS BLUE UL94V-2
PDF
/
Inventory: 7498
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 2.29mm
Length 35.95mm
Technical
VDE Tested Yes
Contact Retention Without
Number of Signal Positions 0
Contact Termination Crimp
Sealable No
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.250 (6.35mm)
Operating Supply Voltage 600V
Empty Shell NO
UL Flammability Code 94V-2
Contact Gender Female
Number of Contacts 12
Approval Agency UL
Current Rating 19A
Depth 26.16mm
Orientation Straight
Pitch 6.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male or Female
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Locking Ramp
Voltage - Rated 600V
Number of Rows 3
Color Blue
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type Panel Mount, Snap-In
Mount Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 12 Weeks
