1-2132781-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING 10POS .156" SNGL
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.5984
≥1 USD $0.5984
≥10 USD $0.57904
≥100 USD $0.413776
≥500 USD $0.362666
≥1000 USD $0.316422
≥3000 USD $0.301233
Inventory: 1421
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 13.3096mm
Length 40.16mm
Height 10.9982mm
Technical
Contact Retention Without
Insulation Diameter 2.9972 mm
Contact Termination Crimp
Contact Current Rating 6.5A
Sealable No
Withdrawl Force-Min .8896 N
Insertion Force-Max 9.7856 N
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 22 AWG
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Contact Resistance 20mOhm
Operating Supply Voltage 600V
Empty Shell NO
UL Flammability Code 94V-0
Body Breadth 0.346 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 6.5A
Depth 13.3mm
Orientation Straight
Total Number of Contacts 10
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Holder
HTS Code 8536.69.40.30
Gender Male
Number of Rows 1
Color Natural
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 10
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Economy Power II
Published 1999
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
