1-1827863-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings RCPT 22P DUAL KEY X
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.9064
≥1 USD $0.9064
≥10 USD $0.84392
≥100 USD $0.812768
≥500 USD $0.804848
≥1000 USD $0.726352
≥3000 USD $0.702794
Inventory: 2597
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 30 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyester
Body Material Glass, Polyester
Technical
Packaging Bulk
Published 2007
Series Dynamic D-1100
Feature Polarizing Key
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle
Number of Positions 22
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Black
Number of Rows 2
Gender Receptacle
Voltage - Rated 125V
Fastening Type Latch Lock
Contact Type Female Socket
Pitch 0.079 2.00mm
Orientation Straight
Depth 11.3mm
Current Rating 2A
Approval Agency UL
Number of Contacts 22
Housing Color Black
Operating Supply Voltage 125V
Row Spacing 0.130 (3.30mm)
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 125V
Wire/Cable Gauge 22 AWG
Sealable No
Circuit Application Signal
Contact Termination Crimp
Halogen Free Halogen Free
Preloaded No
VDE Tested No
Dimensions
Height 11.2776mm
Length 24.6mm
Width 12.45mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
