1-172160-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Pin & Socket Connectors OBSOLETE
PDF
/
Inventory: 3505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Contact Termination Crimp
Withdrawl Force-Min .973 N
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style PLUG
Note Contacts Not Included
Row Spacing 0.163 (4.14mm)
Insulation Resistance 100000000Ohm
Body Depth 0.933 inch
Empty Shell YES
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 105°C
Number of Contacts 6
Body Length or Diameter 0.551 inch
Reliability COMMERCIAL
Reference Standard UL,VDE,CSA
Orientation Straight
Pitch 0.163 4.14mm
Mixed Contacts NO
Contact Type Male or Female
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Gender Female
Number of Rows 2
Color Green
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series Mini-Universal MATE-N-LOK
Published 1999
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
