1-171822-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings RECPT 12 POS 2.5mm
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.43208
≥100 USD $0.430144
≥500 USD $0.415536
≥1000 USD $0.34848
≥3000 USD $0.326691
Inventory: 5445
Minimum: 1
-
+
Technical Details
Technical
Pitch 0.098 2.50mm
Total Number of Contacts 12
Orientation Straight
Depth 14mm
Current Rating 2A
Reliability COMMERCIAL
Approval Agency UL
Body Breadth 0.228 inch
Contact Gender Female
UL Flammability Code 94V-0
Operating Supply Voltage 250V
Rated Current (Signal) 2A
Insulation Resistance 500MOhm
Note Contacts Not Included
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Sealable No
Contact Current Rating 2A
Contact Termination Crimp
Mating Retention With
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Natural
Number of Positions 12
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EI
Published 2005
Packaging Bulk
Dimensions
Height 5.75mm
Length 14mm
Width 5.8mm
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 11 Weeks
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
