1-1586018-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Pin & Socket Connectors 12P PM PLUG V0
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.27368
≥100 USD $0.193741
≥500 USD $0.169805
≥1000 USD $0.151571
≥3000 USD $0.141046
Inventory: 2655
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 23.876mm
Length 26.40076mm
Height 9.6mm
Technical
Contact Retention Without
Insulation Diameter 3.0988 mm
Contact Termination Crimp
Sealable No
Durability 50 Cycles
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.165 (4.20mm)
Rated Current (Signal) 9A
Operating Supply Voltage 600V
Housing Color White, Natural
UL Flammability Code 94V-0
Body Breadth 0.457 inch
Number of Contacts 12
Approval Agency CSA
Reliability COMMERCIAL
Current Rating 9A
Depth 23.9mm
Orientation Straight
Pitch 0.165 4.20mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
HTS Code 8536.69.40.40
Voltage - Rated 600V
Gender Male
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series VAL-U-LOK
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Panel Mount, Snap-In
Mount Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 16 Weeks
