Category Connectors, Interconnects / Rectangular Connectors - Housings
Description AMP-DUAC Rectangular Connector Housing
PDF
/
Inventory: 2827
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 23.9mm
Length 13.7922mm
Height 11.7mm

Technical

VDE Tested Yes
Contact Pattern RECTANGULAR
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 26 AWG
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Compliant
Insulation Resistance 1000000000Ohm
Contact Resistance 5mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 9A
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Male
Row Spacing - Mating 4.191 mm
Reliability COMMERCIAL
Reference Standard UL
Current Rating 9A
Depth 23.9mm
Orientation Straight
Total Number of Contacts 6
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature AMP-DUAC
Number of Rows 2
Color White
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 6
Connector Type Pin, Plug
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Packaging Bulk

Physical

Housing Material Nylon
Shell Material POLYAMIDE
Mount Cable, Free Hanging
