316016-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors 040 PAIR MATE PLUG HSG ASY 22P
PDF
/
Inventory: 2467
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mount Cable, Free Hanging
Insulation Material POLYBUTYLENE TEREPHTHALATE
Shell Material POLYBUTYLENE TEREPHTHALATE
Body Material PBT
Technical
Pbfree Code no
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Socket
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Color Grey
Number of Rows 4
Gender Male
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.6mm
Orientation Straight
Reliability COMMERCIAL
Row Spacing - Mating 4.8 mm
Number of Contacts 22
Empty Shell NO
Body Depth 0.827 inch
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 100000000Ohm
ELV Compliant
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1000VAC V
Durability 30 Cycles
Contact Pattern STAGGERED
Circuit Application Signal
Contact Design PREASSEM CONN
Mating Tab Width 1mm
Hybrid Connector No
Polarized Yes
Dimensions
Height 21.0058mm
Length 25.6mm
Width 25.3mm
Compliance
RoHS Status RoHS Compliant
