3-582151-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Standard Card Edge Connectors 23 AMP BLADE RCPT HSG
PDF
/
Inventory: 7853
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 75.95mm
Technical
Preloaded No
Withdrawl Force-Min 4.448 N
Insertion Force-Max .556 N
Contact Pattern STAGGERED
Polarization Key POLAR PIN POSITION
ELV Compliant
Body/Shell Style PLUG
Contact Style BLADE PIN-SKT
Rated Current (Signal) 5A
Operating Temperature (Min) -65°C
Body Breadth 0.4 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Row Spacing - Mating 3.175 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Depth 18.92mm
Orientation Straight
Total Number of Contacts 23
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature TERMI-POINT
Gender Female
Number of Rows 2
Color Green
Number of Positions 23
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Packaging Bulk
Physical
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Mount Panel
