178690-1 image
Favorite
178690-1 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description 18P NSCC PLUG HSG ASSY
PDF
/
Inventory: 5157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mount Cable, Free Hanging
Material Polybutylene
Body Material PBT

Technical

Pbfree Code yes
Termination Crimp
Connector Type Plug, Socket
Max Operating Temperature 221°C
Min Operating Temperature -22°C
Color White
Number of Rows 2
Gender Male
Fastening Type Ramp
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.9mm
Orientation Straight
Row Spacing - Mating 2.54 mm
Number of Contacts 18
Mating Information 178688-1
Empty Shell NO
ELV Compliant
Circuit Application Signal
Mating Tab Width 1.8mm
Serviceable Yes

Dimensions

Height 21.0058mm
Length 27.4mm
Width 17.2mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Not Applicable
