178689-2 image
Favorite
178689-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Automotive Connectors 14P NSCC PLUG HSG ASSY
PDF
/
Inventory: 9473
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 17.2mm
Length 23mm
Height 21.0058mm

Technical

Serviceable Yes
Mating Tab Width 1.8mm
Circuit Application Signal
ELV Compliant
Empty Shell NO
Mating Information 178688-1
Number of Contacts 14
Row Spacing - Mating 2.54 mm
Orientation Straight
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Ramp
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Connector Type Plug, Socket
Termination Crimp
Pbfree Code yes
Packaging Bulk

Physical

Body Material PBT
Material Polybutylene
Mount Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
