1-1419158-9 image
Favorite
1-1419158-9 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Rectangular Connector Housing
PDF
/
Buying Options
Total Price: USD $1.83
Unit Price: USD $1.829529
≥1 USD $1.829529
≥10 USD $1.725973
≥100 USD $1.628271
≥500 USD $1.53611
≥1000 USD $1.449161
Inventory: 3944
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 24.6888mm
Length 29.9974mm
Height 23.0378mm

Technical

Polarized No
Hybrid Connector Yes
Mating Tab Width 2.794mm
Circuit Application Signal
Wire/Cable Gauge 22 AWG
Empty Shell YES
Contact Gender FEMALE
Orientation Straight
Total Number of Contacts 23
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
Number of Rows 2
Color Blue
Min Operating Temperature -40°C
Max Operating Temperature 212°C
Number of Positions 23
Connector Type Receptacle, Socket
Termination Crimp
Packaging Bulk

Physical

Housing Material Polyamide
Mount Cable, Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
