929682-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors MQS BU-GEH 2X6P
PDF
/
Inventory: 1482
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width 16.002mm
Length 19.4056mm
Height 7.1mm
Technical
Polarized Yes
Hybrid Connector No
Mating Tab Width 635μm
Circuit Application Signal
ELV Compliant
Number of Contacts 12
Row Spacing - Mating 2.54 mm
Depth 16mm
Orientation Straight
Pitch 2.54mm
HTS Code 8536.69.40.30
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Published 2008
Packaging Carton
Physical
Body Material PBT
Housing Material Polybutylene
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 13 Weeks
