530752-2

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Conn Box Connector PIN 70 POS 2.54mm Crimp ST Panel Mount Loose Piece
PDF
/
Inventory: 2081
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)

Physical

Contact Material Brass
Mount Free Hanging, Panel
Housing Material Polyester

Technical

Packaging Bulk
Published 1997
Pbfree Code yes
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Pin, Plug
Number of Positions 70
Color Blue
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 70
Orientation Straight
Depth 26.67mm
Reliability COMMERCIAL
Row Spacing - Mating 2.54 mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.4 inch
Contact Gender MALE
Body/Shell Style RECEPTACLE
ELV Compliant
Polarization Key ENDS
Wire/Cable Gauge 22 AWG
Contact Pattern RECTANGULAR
Sealable No
Mating Retention Without

Dimensions

Height 10.16mm
Length 110.617mm

Compliance

RoHS Status RoHS Compliant
