353027-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors 040 H/D-3 PLUG HSG ASSY 17P
PDF
/
Buying Options
Total Price: USD $2.48
Unit Price: USD $2.4816
≥1 USD $2.4816
≥10 USD $2.21496
≥100 USD $2.001296
≥500 USD $1.619042
≥1000 USD $1.427906
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width 16.51mm
Length 21mm
Height 23mm
Technical
Serviceable Yes
Polarized Yes
Hybrid Connector No
Mating Tab Width 1mm
Circuit Application Signal
Max Voltage Rating (AC) 250V
ELV Compliant
Contact Resistance 15mOhm
Housing Color Natural
Number of Contacts 17
Row Spacing - Mating 4.5974 mm
Depth 21mm
Orientation Straight
Pitch 2.5mm
Fastening Type Latch
Voltage - Rated 250V
Gender Male
Number of Rows 3
Color Natural
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 17
Connector Type Plug, Socket
Termination Crimp
Part Status Active
Published 1999
Packaging Bulk
Physical
Body Material PBT
Housing Material Polybutylene
Mount Cable, Free Hanging
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 13 Weeks
