1747140-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Rectangular Connector Housing
PDF
/
Buying Options
Total Price: USD $11.52
Unit Price: USD $11.5192
≥1 USD $11.5192
≥10 USD $10.41553
≥100 USD $10.139985
≥500 USD $9.754158
≥1000 USD $9.03775
≥3000 USD $8.982635
Inventory: 202
Minimum: 1
-
+
Technical Details
Physical
Contact Material NOT SPECIFIED
Mount Cable, Free Hanging
Housing Material Polybutylene
Body Material PBT
Technical
Termination Crimp
Connector Type Plug, Receptacle, Socket
Max Operating Temperature 140°C
Min Operating Temperature -40°C
Color Black
Number of Rows 4
Gender Male
Voltage - Rated 12V
Contact Finish - Mating NOT SPECIFIED
Pitch 2.9972mm
Orientation Straight
Depth 36mm
Row Spacing - Mating 2.9972 mm
Number of Contacts 60
ELV Compliant
Circuit Application Signal
Mating Tab Width 2.286mm
Serviceable Yes
Dimensions
Height 41.6mm
Length 36mm
Width 70.5mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
