1379913-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors TAB HSG 20P MQS MPQ ASSY YELLOW
PDF
/
Inventory: 7080
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mount Free Hanging
Housing Material Polybutylene
Body Material PBT
Technical
Packaging Box
Published 2006
Pbfree Code yes
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Tab
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Yellow
Number of Rows 2
HTS Code 8536.69.40.30
Pitch 2.54mm
Orientation Straight
Depth 38.7mm
Row Spacing - Mating 5.5118 mm
Number of Contacts 20
ELV Compliant
Circuit Application Signal
Mating Tab Width 2.794mm
Serviceable No
Dimensions
Height 27.85mm
Length 39.6mm
Width 38.7096mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
