1-174923-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Housing PL 6 POS 3.5mm Crimp ST Cable Mount
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.8976
≥100 USD $0.7722
≥500 USD $0.609426
≥1000 USD $0.550986
≥3000 USD $0.516604
Inventory: 1649
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width 24.4094mm
Length 21.6mm
Height 15.9004mm
Technical
Polarized Yes
Hybrid Connector No
Mating Tab Width 1.8mm
Circuit Application Signal
ELV Compliant
Empty Shell NO
Housing Color White
UL Flammability Code 94V-2
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 6
Current Rating 14A
Depth 21.6mm
Orientation Straight
Pitch 3.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch
Gender Female
Number of Rows 1
Color Natural
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Connector Type Plug, Receptacle, Socket
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2005
Packaging Bulk
Physical
Body Material PBT
Housing Material Polybutylene
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 15 Weeks
