IPD1-05-D-P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Housing 10 POS 2.54mm Crimp ST Loose Piece
PDF
/
Buying Options
Total Price: USD $3.82
Unit Price: USD $3.8192
≥1 USD $3.8192
≥10 USD $3.46984
≥100 USD $3.286624
≥500 USD $3.210416
≥1000 USD $3.057472
≥3000 USD $2.67527
Inventory: 189
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 14.17mm
Technical
Contact Termination Crimp
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 30 AWG
Max Voltage Rating (AC) 675V
Note Contacts Not Included
Row Spacing 0.100 (2.54mm)
Depth 12.83mm
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Latch Lock
Number of Rows 2
Color White
Number of Positions 10
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Polarizing Key
Series Mini Mate? IPD1
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Supply Chain
Factory Lead Time 3 Weeks
