IPBD-02-S

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description CONN RCPT HSG 2POS 4.20MM
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.33616
≥100 USD $0.29568
≥500 USD $0.271744
≥1000 USD $0.261096
≥3000 USD $0.234502
Inventory: 1158
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material VALOX 457

Technical

Packaging Tube
Published 2002
Series Power Mate? IPBD
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 2
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Beige
Number of Rows 1
Fastening Type Latch Lock
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.165 4.20mm
Total Number of Contacts 2
Orientation Straight
Depth 19.56mm
Empty Shell NO
Note Contacts Not Included
Max Voltage Rating (AC) 600V
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 16 AWG
Contact Termination Crimp

Dimensions

Length 9.39mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
