90156-0155
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING 15POS .100 CRIMP
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.227409
≥1 USD $1.227409
≥10 USD $1.157928
≥100 USD $1.092383
≥500 USD $1.030554
≥1000 USD $0.972224
Inventory: 3976
Minimum: 1
-
+
Technical Details
Technical
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Depth 15.24mm
Current Rating 3A
Reference Standard UL
Voltage - Rated AC 350V
Reliability COMMERCIAL
Lead Pitch 2.54mm
Number of Contacts 15
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 5GOhm
Body/Shell Style PLUG
Durability 500 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 2.9468 N
Halogen Free Low Halogen
Glow Wire Compliant Non-compliant
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Gender Receptacle
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2002
Packaging Bulk
Dimensions
Length 39.16mm
Width 5.35mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material PPO
Material Polyphenylene
Mount Free Hanging
Supply Chain
Factory Lead Time 7 Weeks
